Fascenario.X Launch Edition

Fascenario Goes Gravel

At the heart of the Fascenario.X is a lightweight carbon frame derived directly from the successful Fascenario platform. This foundation has been specifically refined for gravel riding and paired with specially selected components. The sporty geometry combines the direct power transfer of a road bike with the control and stability required on gravel and challenging terrain. The result is a bike that remains composed even at high speeds while offering maximum efficiency.

Lightness Meets Speed

With a complete weight starting at just 7.1 kg, the Fascenario. X sets new standards in the high-performance gravel bike segment. This exceptional lightness enables direct acceleration, high agility, and a riding experience typically reserved for classic road bikes. At the same time, the sophisticated frame construction ensures the necessary robustness and control on loose terrain—a combination that makes the Fascenario.X one of the fastest gravel bikes in its class.

Performance with a sophisticated finish

The Launch Edition features the exclusive “Sparkling Dark Emerald Green” color scheme. The deep, dark green reveals a subtly shimmering, metallic depth in the light and highlights the frame’s elegant lines. The gold decals complete the sophisticated finish, perfectly blending performance and aesthetics.

Perfectly matched components

The Launch Edition offers a selection of high-end drivetrains, each tailored to different riding styles and requirements: All variants guarantee precise shifting, high reliability, and optimal performance—even under the most demanding conditions. The Fascenario.X Launch Edition is also equipped with Zeitjaeger Platinum 45G wheels, specially optimized for gravel riding. The combination of aerodynamic efficiency, low weight, and high stability ensures confident handling on a wide variety of surfaces.

Your Fascenario.X Launch Edition

Frame geometry

Frame SizeST (mm)TT EFF (mm)HT (mm)CS (mm)Stack (mm)Reach (mm)ST° (degree)HT° (degree)Recommended body height (cm)Handlebar width/stem length (mm)
XS450511,9100422522,636774,570150 - 164380/95
S485532,9120422547,23767471,5161 - 173400/105
M515558,3145422571,738973,572170 - 182400/115
L540578170422595,53967372178 - 189400/115
XL565595195422618,34067372,5185 - 195420/115
XXL588615,5220422642,141372,572,5191 - ...420/125
Legende:
  • ST: seat tube length • Sitzrohr (mm)
  • TT EFF: effective top tube length (mm)
  • HT: head tube • Steuerrohr (mm)
  • CS: chain stay length • Kettenstrebe (mm)
  • F: fork rake (mm)
  • Stack: vertical length center bottom bracket to center top head tube (mm)
  • Reach: horizontal length center bottom bracket to center top head tube (mm)
  • ST°: seat tube angle (degree)
  • HT°: head tube angle (degree)
size-chart-frames
Specification
Brakes: Shimano RT-CL800 160mm
Cassette: XT M8100 10-51 12-speed Hyperglide
Chain: CN-M8100 HG 12-speed 126G Quick-Link
Front derailleur: Shimano GRX RX820
Handlebar/ stem unit: GBSU Fascenario.X LE
Handlebar tape: Storck Gravel black 2,5mm
Inner bearing: BB386, 46x86.5 mm
Material: Carbon Fibre Reinforced (CFR)/Unidirectional (UD)
Rear derailleur: Shimano GRX RX822 12-fach
Saddle: Fizik Terra Argo X5 150mm
Seat post: Fascenario.X black
Tax rate: Fascenario.X
Colour: Sparkling Dark Emerald Green
Frame variant: Launch Edition
Groupset: Shimano GRX 822 1x12
Size: XS
Wheelset: Storck Zeitjaeger Platinum 45 G green
