Aernario.3 Platinum Max Performance
Extreme lightweight construction down to the last detail
With the Aernario.3 Platinum Max Performance, Storck Bicycle is setting new standards in high-end lightweight construction. Based on the proven Aernario.3 Platinum, meticulous development work led by CTO Max Fetzer has resulted in a road bike designed consistently for minimal weight and maximum efficiency. The result is an uncompromising performance bike that, with a total weight of around 5.3 kg, reaches new heights in the disc road bike segment.
Maximum performance through radical lightweight construction
At the heart of the Aernario.3 Platinum Max Performance is a specially selected superlight carbon frame, which, in combination with an ultralight fork, forms the foundation of this extraordinary project. Every single component has been specifically chosen to minimize weight without compromising on stiffness, riding safety, or performance. The result is a bike that responds directly, agilely, and extremely efficiently to every pedal stroke. The characteristic Aernario geometry ensures a balanced ratio of comfort and race performance—ideal for demanding climbs, long distances, and maximum acceleration.
Top-tier components
The Aernario.3 Platinum Max Performance is equipped with exceptionally lightweight yet high-performance components that are perfectly tailored to the overall design. From the drivetrain to the cockpit and wheels, every detail has been engineered to maximize weight savings and efficiency. This uncompromising approach makes the model one of the most consistently lightweight road bikes on the entire market.
Developed with a passion for perfection
The project was led by CTO Max Fetzer, who infused every detail with his extensive expertise in carbon development and lightweight construction.
“With the Aernario.3 Platinum Max Performance, we wanted to demonstrate what is technically possible when you scrutinize every detail and consistently optimize for lightweight construction. The result is a road bike at the absolute top level.” – Max Fetzer, CTO Storck Bicycle
Your Aernario.3 Platinum Max Performance
Frame geometry
| Frame Size | ST (mm) | TT (mm) | TT EFF (mm) | HT (mm) | CS (mm) | Stack (mm) | Reach (mm) | ST° (degree) | HT° (degree) | Recommended body height (cm) | Crank length (cm) | Handlebar width/stem length (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 475 | - | 545 | 132 | 407 | 543,1 | 387,2 | 73,8 | 72,5 | 165 - 174 | 170 | 380/90 |
| M | 500 | - | 566 | 158 | 407 | 571,2 | 396,8 | 73,5 | 73,5 | 174 - 182 | 172,5 | 400/100 |
| L | 525 | - | 582 | 182 | 407 | 594,2 | 406 | 73,5 | 73,5 | 180 - 189 | 172,5 | 420/100 |
| XL | 550 | - | 599 | 206 | 407 | 617,2 | 416,2 | 73,5 | 73,5 | 187 - 195 | 175 | 420/110 |
| XXL | 580 | - | 610 | 229 | 407 | 639,2 | 420,7 | 73,5 | 73,5 | 193 - 203 | 175 | 440/120 |
- ST: seat tube length • Sitzrohr (mm)
- TT: top tube length • Oberrohr (mm)
- TT EFF: effective top tube length (mm)
- HT: head tube • Steuerrohr (mm)
- CS: chain stay length • Kettenstrebe (mm)
- F: fork rake (mm)
- Stack: vertical length center bottom bracket to center top head tube (mm)
- Reach: horizontal length center bottom bracket to center top head tube (mm)
- ST°: seat tube angle (degree)
- HT°: head tube angle (degree)
| Brake/shift levers: | SRAM Red E1 AXS |
|---|---|
| Brakes: | Brakco AL 7075 carrier 140mm |
| Cassette: | SRAM Red E1 AXS 12-fach XG-1290 10-36 |
| Chain: | SRAM Red E1 AXS 12/13-fach |
| Crank / chainring: | Kettenblatt Gemini Rigel Road 46Z, Kurbelarme SRAM Red E1 DUB 12-fach |
| Handlebar tape: | Storck microfibre black |
| Material: | Carbon Fibre Reinforced (CFR)/Unidirectional (UD) |
| Rear derailleur: | SRAM Red AXS E1 12f. max 36Z |
| Saddle: | Alpitude Gardena 128mm UD |
| Seat post: | Storck SP-92K 370 mm |
| Tax rate: | Aernario.3/Aerfast3 |
| Tyres: | Conti Grand Prix 5000 black/black FB 25mm |
| Colour: | Matt Black |
| Frame variant: | Platinum |
| Groupset: | SRAM Red E1 AXS 1x12 |
| Size: | S |
| Wheelset: | Scope Artech 2 22mm |
